WC Fab 60" Traction Bar Kit, 2011-2019 LML/L5P

Part# WCF100851


WARNING: Cancer and Reproductive Harm - www.P65Warnings.Ca.Gov

Fits: 2011 thru 2019 Chevy Silverado/GMC Sierra 2500HD/3500HD LML/L5P

Duramax Diesel Regular Cab Longbed, Crew Cab Shortbed, & Extended Cab Shortbed

​Traction bars are a necessary upgrade when increasing the horsepower to prevent the axle from twisting which can lead to broken u-joints, driveshafts, and even twisted axle housings. Wehrli Custom Fabrication's traction bar brackets bolt onto the bottom of the axle tube via the axle u-bolts and weld to the frame on the front end.


  • High quality serviceable RockJock Johnny Joints
  • Polyurethane bushings for decreased noise & vibrations
  • Lifetime warranty against bending or breaking to original purchaser


  • 60" Heavy duty bars
  • Poly bushings
  • RockJock Johnny Joints
  • Frame side weld-on mounts
  • Axle side brackets
  • Grade 8 hardware
  • Custom color powder coat POWDERCOAT COLOR CHART


  • Front frame brackets can be bolted on, welding recommended for maximum strength & competition use
  • If you have a regular cab long bed, please measure forward 60" from the bottom of the rear axle and verify that you have a good spot on the frame to land the front mounting brackets, some models have brackets for the fuel tank, which interfere with 60" bar frame side mounting points and should run WCF100853
  • If you have a lift kit and your u-bolts face up instead of down like factory, use traction bar kit WCF100855
  • If your truck is on a big lift, please measure from your axle mounting point to your frame mounting point to ensure the bar length will work properly for your application before ordering
  • If you have a lift kit and your rear lift Block is taller than 5" or your total lift height is 6" or greater, use part number WCF100853
  • 15+ business days before shipment, this is a custom order part, once the order has been processed it CANNOT be canceled, returned, or refunded
  • If you enter a powdercoat color that is not listed on the chart, your order will be delayed as we will have to contact you to discuss the options. RAW Finish is NOT available!
