Fits: 2001 thru 2010 Chevy Silverado/GMC Sierra 2500HD/3500HD LB7/LLY/LBZ/LMM Duramax Diesel
All 2001-2010 6.6L Duramax's need a lift pump! Your Silverado/Sierra doesn’t come with a factory lift pump like other diesel pick-ups which forces the injection pump to "pull" fuel all the way from the tank, creating a vacuum which constantly introduces more air and vapor into your fuel. The FASS Titanium Signature Series Lift Pump creates a positive flow, "pushing" fuel to your injection pump, eliminating vacuum and drastically reducing air and vapor.
The Titanium Signature Series diesel fuel lift pump was engineered by FASS Fuel Systems to be the top performing, longest lasting and most reliable aftermarket filtration system in the diesel industry. Rated at 165 Gallons Per Hour and backed by a Limited Lifetime Warranty the Titanium Signature Series lift pump is capable of supporting your GM Duramax 6.6L diesel engine with enough fuel for multiple fueling system upgrades. A Titanium Signature Series lift pump also offers advanced filtration benefits that will help protect your Duramax’s injection systems, effectively extending the life of your Injection Pump and Injectors. These Benefits include an improved filtration rating of 2 Microns, a built in water separation filter and FASS Fuel Systems patented air/vapor removal process. Duramax diesel engines are known for having injector failure issues; this can be caused by several different factors and FASS Filtration Systems is designed to eliminate those that are fuel related.
Features:
- Pre-set to 8-10psi
- Flows 165GPH, Supports up to 600-900HP
- Removes Water, Air & Debris From Fuel
- Protects & Extends The Life of your Injectors and Injection Pump
- Improved Fuel Economy
- Smoother Engine Idle
- Quietest Pump Motor On The Market
- Includes Everything For Installation
- No Tuning Required
- Limited Lifetime Warranty
Includes:
- Lift Pump
- Particulate Filter & Water Separator
- Wiring Harness
- Mounting Bracket
- Hardware
DmaxStore Note:
- The 165GPH will cover up to 600-900HP on your Duramax.
- This is a common selection for those at or just below 600HP if they plan on running the truck hard.
- Be sure to register your pump ASAP to activate your Limited Lifetime Warranty
- Fuel Filter Delete: You can delete the factory fuel filter if you are running a lift pump with filters.
- DmaxStore Fuel Filter Eliminator: This is our preferred option. It can be difficult to get a good grip on the housing when is it smooth and round, hence our design.
- FASS Fuel Filter Delete: Great option built by FASS.
Warranty:
- Limited Lifetime Warranty upon completion of FASS's REGISTRATION FORM.
CARB EO# D-713
INSTALL INSTRUCTIONS (Take note of your pumps manufacturer date to select the correct instructions.)
Additional Information:
- FASS Whisper Technology (FWT) was engineered to meet the stringent demands of today’s quiet diesel engines. FASS Whisper Technology was in development and testing for over two and a half years to meet FASS Fuel System’s high quality and durability standards. FASS Whisper Technology effectively and drastically reduces the sound levels of the Signature Series FASS Diesel Fuel System to a “whisper” while at the same time increasing fuel flow rates. Our competition reduces noise levels by reducing flow rates.
- Performance Radius Cuts (PRC) are an advanced machining technique used to improve the flow of fuel through the FASS System by creating smooth flowing cuts within the aluminum housing. This prevents the reintroduction of air and vapor back into the fuel and to prevent eddy currents from forming within the corner of a 90-degree sharp angle. FASS Titanium Signature Fuel Systems are the only Fuel Air Separation System that incorporates these exclusive Performance Radius Cuts, lesser competitors commonly use T-Bone and square 90-degree fittings that can limit fuel flow, cause restrictions and reintroduce air back into your fuel.
- Mass Flow Return (MFR) technology is used to continually polish your fuel by keeping a positive pressure on the fuel being delivered to the engine to prevent cavitation along with galling and scoring. Then returning the fuel, that’s not yet needed, back to the tank after it has been passed through the filtration process, removing dirt, air, vapor and water. This means your fuel is being constantly “Polished” (cleaned), guaranteeing that your diesel truck always has the cleanest fuel possible. The MFR in combination with the optional FASS Fuel Heater options will help insure “EXTREME” cold weather operations!
- Bolt On Bracket Mounts old mounting styles required drilling or welding when mounting your new pump. This has now been simplified with our new bolt on brackets that utilize your Ford Super Duty factory bed bolt, the bolt that secures your truck bed to your frame. Mounting your Titanium Signature Series lift pump takes only minutes and all brackets are made from machined steel for superior support and strength.
