Fits: 2011 thru 2019 Chevy Silverado/GMC Sierra 2500HD/3500HD LML/L5P Duramax Diesel

Upgrade your 2011-2019 Chevy Silverado or GMC Sierra 2500HD/3500HD truck with a 3-inch suspension lift kit featuring FOX 2.5 Coil-Over conversion, engineered to enhance stance, performance, and capability. This comprehensive kit includes all necessary components to accommodate up to 35" tires, providing increased clearance and optimized travel for tackling rough terrain while ensuring smooth on-road comfort.

The kit replaces factory torsion bars and upgrades both upper and lower control arms to enhance strength, travel, and compatibility with the new coilovers. Crafted from robust materials, the upper control arms boast large 1.5" OD x .120-wall tubing, meticulously TIG welded for superior durability. Meanwhile, the lower control arms are constructed from high-strength steel, fully boxed and internally gusseted for added resilience.

Engineered according to BDS's renowned standards, this kit prioritizes improved ground clearance, strength, and off-road protection while rectifying suspension and steering geometry for exceptional on-road handling. The front suspension lift comprises FOX 2.5 coil-over shocks, heavy-duty tubular upper control arms, fully boxed and gusseted lower control arms, and multipiece differential relocation brackets to ensure correct CV angles. Additionally, provided sway bar links and hardware contribute to a comprehensive front suspension lift that can handle any challenge.

For the rear, BDS offers replacement lift blocks to level the stance without compromising ride quality or load capacity. A u-bolt flip kit ensures maximum clearance, while precision-tuned FOX 2.0 Performance Series shocks deliver optimal off-road performance

Experience unparalleled performance both on and off the road with FOX 2.5 Coil-Overs, engineered to elevate your driving experience to new heights. These 2.5-inch diameter coil-overs are designed to withstand the toughest conditions, featuring race-proven technology and a remote reservoir for increased fluid capacity, ensuring optimal performance even in challenging terrain.

Opt for the optional DSC (dual speed compression) adjustment to fine-tune high-speed and low-speed compression damping for enhanced control on various surfaces. With two clearly defined knobs, adjusting damping settings is intuitive and provides immediate feedback, allowing you to customize your ride for any terrain with ease.

Our HD Control Arms are meticulously crafted for durability, performance, and extended travel, providing a seamless bolt-in solution. The upper arms boast 1.5" OD x .120-wall tubular construction with an indexed ball joint cup, allowing for additional down travel and camber adjustment. Meanwhile, the lower control arms are constructed from high-strength steel, fully boxed and internally gusseted for maximum resilience. Durometer-specific rubber bushings at the frame mounting ends ensure maintenance-free operation, while quality greaseable ball joints at the other end ensure smooth, quiet operation and long-lasting durability. Finished in a durable black powder coat with billet aluminum dust caps, these control arms are ready for installation straight out of the box.

Features:

• Improve stance, performance, and capability
• Clearance up to 35" tires
• Fox 2.5 Coilovers for better performance
• Easily adjustable dual speed compression for added control
• Strengthened UCA for greater performance and travel
• Front lift height: 3"
• Rear lift height 2"
• Factory protection plus drivetrain warranty

Includes:

• Set of heavy duty tubular upper control arms
• Set of Fox 2.5 coilover shocks
• Set of Fox 2.0 performance series shocks
• Set of boxed and gusseted lower control arms
• Differential relocation brackets
• Sway bar links
• Replacement lift blocks
• U-Bolt flip kit
• Necessary hardware

Notes:

• Some metal trimming may be required with 35x12.5R20 on 20x9 w/5-5.5" BS
• Some welding required
• Factory 17", 18" and 20" wheels cannot be reinstalled. Please review the instructions for more information.
• Dually models will need 20" aftermarket wheels with a max tire size of 285/60/20.
• Coilovers are present to a 2" minimum height.
• All BDS Lift kits are special order, Please allow 12-24 weeks before kits ship.
• If shock boots are purchased, you will get 2 shock boots for the rear shocks.
• Free Standard freight is only to the lower 48  states.  International, HI, and AK, orders will require an additional shipping charge before order is shipped.
